Hydraulic Mobile Bin Automatic Continous Baler

TCM-HPAA series fully automatic horizontal baler, applicable for recyclers handling large daily amount of soft waste such as cardboard/OCC ( popular as cardboard baler or OCC baler ) , paper, plastic film, natural fiber, textile waste, soft plastic packag

  • Series:HPAB
  • Payment:T/T
  • Port:ShangHai
Click To Inquire
  • Details
  • Application
  • Parameter


TCM-HPAB series fully automatic horizontal baler use the latest design, simple frame and solid structure.  Open type structure makes packaging conveniently, and improves work efficiency. Three sides convergent way, counter loop type, tightening and loosening through the oil cylinder automatically. And the vessel classification of welding process to ensure that equipment is more stable and reliable.Full-automatic operation, easy to learn ,operate and maintain. Configures with PLC program and touch screen control, operated simply and equipped with automatic feeding detection, can compress bale automatically, realize unmanned operation, designs as special automatic strapping device.

Adjustable Bale size and weight on customer’s requirement. The bale length and weight can be set arbitrarily, and accurately record data of balers. Also the bale size and voltage can be customized according to customers' reasonable requirements. Bales weight depends on different materials.Adopt foreign famous seal, valve, electric components Adopt the German hydraulic technology to save energy and protect environment, and the YUKEN valve group, Schneider appliances, seals are imported form British to ensure without phenomenon of oil leak and improve the service life of the cylinder.

Our fully automatic horizontal balers are designed to process a wide range of material that can be recycled, paper, cardboard, film, textiles, PET bottles, aluminium cans. The fully automatic horizontal baler range are manufactured using thick steel sections and profiled sheet giving strength & rigidity to the overall structure. Feeding system can be mechanical, pneumatic or manual and have different options regarding wiring of the bales, vertical or horizontal, with the tying system being automatic or manual. Our fully automatic horizontal balers capacity can vary from 20Tn to 350Tn. These fully automatic horizontal balers have optional auxiliary devices such as a rammer, bin lift, bypass, bale exit device, disperser of material, etc to make a more productive baling process promoting the degree of automation of the installation. A market leading feature is that if you install a MHM fully automatic horizontal baler machine with a 2.5-3T per hour performance and your baling requirement increases you would only have to replace the motor to a larger one instead of paying for a new machine, drastically reducing your costs and doubling its initial output capacity.



Model Hydraulic power Bale size (W*H*L) mm Packing density (kg/M)³ Strapping Number Production Rate Motor(Kw/Hp) Size (L*W*H) mm
HPAB30 30 500*500*(300-1000) 250-300 3 1-1.5 11Kw/15Hp 5000*2750*1800
HPAB40 40 720*720*(300-1500) 350-450 4 1.5-2.5 15Kw/20Hp 6500*3200*1950
HPAB60 60 750*850*(300-1600) 400-500 4 3-4 22Kw/30Hp 6900*3300*2100
